Waveshare 2.66 inch 296 x 152 Pixel Black / White E-Paper E-Ink Display Module for Raspberry Pi Pico, SPI Interface

Name: Waveshare 2.66 inch 296 x 152 Pixel Black / White E-Paper E-Ink Display Module for Raspberry Pi Pico, SPI Interface
Brand: WAVESHARE
SKU: DIY0184
Price: 509.00 ZAR
Availability: InStock

R 509.00

Sale Sold out

FREE DELIVERY on all orders.

hurry! almost sold out...

FREE Shipping

FREE SHIPPING on all orders. Fully Insured.

Handling time 1 - 3 working days. (PMC has to process your order and put all your items through its strict quality-control tests.)

Transit time 7 - 15 working days.

Get It Now, Pay Later

Pay using Mobicred. Simply choose Peach Payment >> Mobicred at checkout, and we’ll ship it once the order is approved.

Return Guarantee

For whatever reason if you are unsatisfied with your order within 7 days you can return it to us in new condition for a refund minus the shipping charges.

Payment & Security

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Missing/Wrong Items Guarantee

If you receive a parcel with missing/incorrect/secondary packing items, please contact us within 7 days of delivery and provide the relevant proof. PMC will make compensation based on the damage situation.

Features
1. No backlight, keeps displaying last content for a long time even when power down
2. Ultra low power consumption, basically power is only required for refreshing
3. SPI interface, requires minimal IO pins
4. Comes with development resources and manual (Raspberry Pi Pico C/C++ and MicroPython examples)

Specification
1. Operating voltage: 3.3V
2. Display color: Black, white
3. Resolution: 296 x 152 pixels
4. Grey scale: 2
5. Interface: 3-wire SPI, 4-wire SPI
6. Viewing angle: Greater than 170 degree
7. Partial refresh time: 0.3s
8. Full refresh time: 2s
9. Dimensions: 74.00 x 37.50mm
10. Display size: 60.088 x 30.704mm
11. Refresh power: 42.4mW(typ.)
12. Standby current: Less than 0.01uA (almost none)
13. Dot pitch: 0.203 x 0.202mm

Package List
1. Pico-ePaper-2.66 x1
2. Standoff pack x1
