Waveshare 1.9inch 262K Colors 170x320 LCD Display Module for Raspberry Pi Pico, SPI Interface, 23822
Waveshare 1.9inch 262K Colors 170x320 LCD Display Module for Raspberry Pi Pico, SPI Interface, 23822
Sale
Sold out
Pre-order
Regular price
R 409.00
Regular price
Sale price
R 409.00
Unit price
per
Ships in 1-3 Days
Estimated delivery:
✓ Delivered Duty Paid: No additional customs charges. All duties and taxes are included.
Couldn't load pickup availability
Guaranteed Safe Checkout
Guaranteed Safe Checkout
Description
• Product type: LCD & LED Display Module
• Brand: Waveshare
• Compatibility: Raspberry Pi Pico
• Material: IPS
• Key feature: SPI interface
• Color/Variant: 262K colors
• Intended use: Everyday use
• Category: Arduino & SCM Supplies
Features:1. Embedded ST7789V2 driver chip, using SPI interface2. 170x320 resolution, 262K colors, clear and colorful displaying effect3. SPI interface, minimizes required IO pins, supports controller boards like for Raspberry Pi/Arduino/STM324. Comes with online development resources (examples for Raspberry Pi/Arduino/STM32)5. Onboard voltage translator: compatible with 3.3V / 5V power Input6. Onboard SPI control interface: for use with controller boards like for Raspberry Pi / Arduino / STM32Specifications:1. Operating voltage: 3.3V / 5V2. Resolution: 170 x 320 pixels3. Communication interface: 4-wire SPI4. Display panel: IPS5. Driver: ST7789V26. Display size: 22.70 × 42.72 mm7. Pixel size:0.1335 × 0.1335 mm8. Module size: 27.3 × 51.2mm- BL: Backlight- RST: Reset, low active- DC: Data/Command selection (high for data, low for command)- CS: Chip selection, low active- CLK: SPI clock input- DIN: SPI data input- GND: Ground- VCC: Power (3.3V / 5V input)
• Brand: Waveshare
• Compatibility: Raspberry Pi Pico
• Material: IPS
• Key feature: SPI interface
• Color/Variant: 262K colors
• Intended use: Everyday use
• Category: Arduino & SCM Supplies
Features:1. Embedded ST7789V2 driver chip, using SPI interface2. 170x320 resolution, 262K colors, clear and colorful displaying effect3. SPI interface, minimizes required IO pins, supports controller boards like for Raspberry Pi/Arduino/STM324. Comes with online development resources (examples for Raspberry Pi/Arduino/STM32)5. Onboard voltage translator: compatible with 3.3V / 5V power Input6. Onboard SPI control interface: for use with controller boards like for Raspberry Pi / Arduino / STM32Specifications:1. Operating voltage: 3.3V / 5V2. Resolution: 170 x 320 pixels3. Communication interface: 4-wire SPI4. Display panel: IPS5. Driver: ST7789V26. Display size: 22.70 × 42.72 mm7. Pixel size:0.1335 × 0.1335 mm8. Module size: 27.3 × 51.2mm- BL: Backlight- RST: Reset, low active- DC: Data/Command selection (high for data, low for command)- CS: Chip selection, low active- CLK: SPI clock input- DIN: SPI data input- GND: Ground- VCC: Power (3.3V / 5V input)
Questions about features, compatibility, or warranty? Chat with our support team!
